System, Safety & Compute

Clock-Loss Monitor

A configurable clock-loss / clock-presence monitor delivered as synthesizable SystemVerilog soft-IP (Hercules safety-MCU gap G-2).

Request this IP →Browse the catalog
ASIL-D
target
99.00%
SPFM
95.00%
LFM
PASS
FMEDA
953
gates
1.0.0
version
The deliverable

What you’re licensing

A configurable clock-loss / clock-presence monitor delivered as synthesizable SystemVerilog soft-IP (Hercules safety-MCU gap G-2). It is delivered as a licensable soft-IP block engineered as an ASIL-D Safety Element out of Context — not just RTL, but the complete functional-safety work package needed to carry it into an ISO 26262 program:

Synthesizable RTL
Portable, vendor-neutral SystemVerilog that drops onto your existing SoC fabric — no foundry or EDA-tool lock-in.
Per-IP FMEDA report
SPFM / LFM / PMHF computed against the ASIL target per ISO 26262-5 — the quantitative analysis your assessor asks for.
Safety manual
Assumptions of use, the safety mechanisms and their diagnostic coverage — written to drop straight into your safety case.
IP-XACT + integration docs
A machine-readable descriptor plus register and integration documentation for fast, low-risk bring-up.
Self-checking testbench
A self-checking (crypto: bit-exact) testbench and a one-command build, so you can reproduce every claim on day one.

What it is

A configurable clock-loss / clock-presence monitor delivered as synthesizable SystemVerilog soft-IP (Hercules safety-MCU gap G-2).

Key Features

Standards & Compliance

ISO 26262 (SEooC)

Functional Safety

ASIL-D (SEooC) · SPFM 99.00% · LFM 95.00% · PASS

ISO 26262:2018 · FMEDA available · Safety Manual included

Register Map

See datasheet for full register reference.

Getting Started

// Minimal instantiation
clk_mon #(
  .ADDR_W(6)
) u_clk_mon (
  .clk       (clk),
  .rst_n     (rst_n),
  // APB4
  .p_paddr   (paddr),
  .p_psel    (psel),
  .p_penable (penable),
  .p_pwrite  (pwrite),
  .p_pwdata  (pwdata),
  .p_prdata  (prdata),
  .p_pready  (pready),
  // Safety
  .err_clear (1'b0),
  .err_valid (err_valid),
  .err_code  (err_code)
);

Configure via the CTRL register after reset to enable the IP and set operating parameters. Monitor err_valid / err_code for any safety faults reported by the built-in safety monitor.

Applications

Where it fits

Typically deployed in the safety backbone of an ASIL SoC — error detection, redundancy, and the fault-reaction path that takes the system to a safe state.

The case

Why license it, not build it

Skip 12–18 months
The FMEDA and the safety case are already generated. You integrate a finished safety element — you don’t stand up a safety-IP program to originate one.
One vendor, one safety story
Every block in the catalog shares the same safety architecture, fault-reaction model, and FMEDA methodology — so subsystems roll up cleanly.
Verified, not vapor
The RTL builds and passes today; the safety metrics come from analysis and fault injection against real RTL, not a datasheet promise.

Interested in Clock-Loss Monitor?

Pricing, the per-IP FMEDA, safety manual, and RTL data room are shared under a mutual NDA.

Talk to us →See related IP

Figures are pre-silicon engineering-grade estimates for a Safety Element out of Context (SEooC); final ASIL sign-off is the integrator’s, supported under NDA. FMEDA and Safety Manual available under NDA.
